Read guide →A diesel tank that is too small means frequent deliveries and the risk of running dry. One that is too big ties up money in fuel and space. Here is a simple way to size a tank for a factory, estate, site or farm.
1. Work out how much diesel you use in a day
Start with your generators, because they are usually the biggest users. How much fuel a generator burns depends on its size and how hard it is working. The spec sheet for your generator lists fuel use at different loads, and that is the most accurate number to use.
If you do not have it, here is a rough guide: a diesel generator uses about 0.25 to 0.3 litres an hour for every kW it is producing. A 100 kVA generator running at three-quarter load produces about 60 kW, so it burns roughly 15 to 18 litres an hour.
Multiply litres per hour by the hours it runs each day. Then add any trucks, forklifts, boilers or other machines you fuel from the same tank.
2. Decide how many days of fuel you want to hold
Think about how often you can get a delivery and how reliable your supplier is. Many businesses keep enough for one to two weeks, with extra cover for festive periods and fuel scarcity.
Days of cover x daily use = working capacity.
3. Add headroom
You should never fill a tank to the brim, and you should not run it to empty, because sediment and water collect at the bottom. Add about 10 to 15 percent on top of your working capacity.
A quick example
- Two 100 kVA generators, 10 hours a day, about 16 litres an hour each: 320 litres a day
- A delivery every 10 days: 3,200 litres
- Plus 15 percent headroom: about 3,700 litres
A 4,000-litre tank would suit this site, with a little room to grow.
4. Check your space and access
Measure where the tank will sit. Check that a delivery truck can reach the fill point, and how far the fuel has to travel to your generator. Make sure the ground can take the full weight: diesel weighs about 0.84 kg per litre, so 4,000 litres of fuel is more than 3 tonnes before you add the tank itself.
5. Choose the type of tank
Once you know the size, decide between a bunded or non-bunded tank, on-ground or overhead, and one compartment or split compartments for diesel and petrol. Our guide to bunded vs non-bunded tanks explains the difference.
Let us size it with you
Send us your generator sizes, running hours and the space you have, and we will recommend a size and build it. See our diesel tanks or get a quote.
